Kub kub cable
Daim ntawv thov:
Cov khoom no yog cov xaim thiab cable siv nyob rau hauv ntau yam khoom siv hluav taws xob uas yuav tsum tau muaj kev ua haujlwm tsis zoo hauv qhov chaw tshwj xeeb xws li metallurgy, thermal engineering, roj av, tshuaj lom neeg kev lag luam, roj av, thiab roj av. Tsau tso, nplaim taws kub hnyiab, tsis muaj teeb meem thiab cov pa phem.
 |
 |
 |
Kab Kab:
Khoom nta:
1. Rated voltage: 300/500V
2. Ua haujlwm kub: -60- ntxiv rau 500 degree
3. Tus neeg xyuas pib: stranded nickel-plated tooj liab hlau
4. Rwb thaiv tsev: iav fiber ntau braiding ntxiv rau Mica daim kab xev
5. Xim: liab / daj / xiav / dawb / dub / daj-ntsuab / xim av / txiv kab ntxwv / ntshav / ntsuab / thiab lwm yam.
Khoom parameter
|
Nominal seemcheeb tsam |
Tus coj |
rwb thaiv tsev thickness |
Cable txoj kab uas hla |
20 degreeconductor kuj |
Ntim Ntev |
|
(mm2） |
Tsis muaj./txoj kab uas hla(mm) |
(mm) |
(mm) |
(Ω/km) |
（m） |
|
0.5 |
7 × 0.30 |
0.5 |
2.3 ± 0.3 |
40.8 |
200 |
|
0.75 |
11 × 0.30 |
0.5 |
2.5 ± 0.3 |
24.3 |
200 |
|
1 |
14 × 0.30 |
0.5 |
2.6 ± 0.3 |
20 |
200 |
|
1.5 |
21 × 0.30 |
0.5 |
2.9 ± 0.3 |
12.6 |
100 |
|
2 |
28 × 0.30 |
0.6 |
3.3 ± 0.5 |
9.84 |
100 |
|
2.5 |
35 × 0.30 |
0.6 |
3.6 ± 0.5 |
7.37 |
100 |
|
4 |
56 × 0.30 |
0.8 |
4.7 ± 0.5 |
4.83 |
100 |
|
6 |
84 × 0.30 |
0.8 |
5.5 ± 0.5 |
3.26 |
100 |
|
10 |
84 × 0.40 |
0.8 |
6.6 ± 0.5 |
1.8 |
100 |
|
16 |
228 × 0.30 |
0.8 |
7.8 ± 0.5 |
1.31 |
100 |
|
126 × 0.40 |
0.8 |
7.8 ± 0.5 |
1.31 |
100 |
|
|
25 |
196 × 0.40 |
0.8 |
9.5 ± 0.5 |
0.758 |
100 |
|
361 × 0.30 |
0.8 |
9.5 ± 0.5 |
0.758 |
100 |
|
|
35 |
494 × 0.30 |
1 |
11.2 ± 1.0 |
0.548 |
100 |
|
50 |
396 × 0.40 |
1.2 |
13.2 ± 1.0 |
0.384 |
100 |
|
703 × 0.30 |
1.2 |
13.2 ± 1.0 |
0.384 |
100 |
|
|
70 |
551 × 0.40 |
1.2 |
15.4 ± 1.0 |
0.289 |
100 |
|
988 × 0.30 |
1.2 |
15.4 ± 1.0 |
0.289 |
100 |
|
|
95 |
760 × 0.40 |
1.2 |
17.4 ± 1.0 |
0.205 |
100 |
